JIYI Terrain Follow Radar Sensor For K++V2 In India

The ground like radar module uses millimeter-wave radar technology. Through continuous scanning of the radar, the aircraft can sense the terrain change in the flight direction, and adjust the flying height in time according to the terrain and crop height to achieve ground-like flight and ensure uniform spraying in flight . The ground-like radar module has stable detection performance and good environmental applicability, strong anti-interference ability, not affected by light, long detection distance, and has the characteristics of all weather and all day.

Features:

1. Strong penetrability (including fog, smoke, dust, light rain) is not affected by light
2. Strong anti-interference ability, good environmental applicability
3. Stable performance, detection distance of 15m
4. Power saving and high efficiency, The total power consumption is only 1.5W
5. It works all day and all days
6. Small size and light weight

Specification:

1. Product Weight: <50g
2. Center Frequency : 24.125Ghz
3. Modulation Mode: FMC
4. Usage Environment: No obstruction below Try to stay away from water mist
5. Altimetry Range: 0. 3-15m(Relative to the ground)
6. Altimetry Accuracy: 0. 05m
7. Output Frequency: 50Hz
8. Power Waste: 1. 5W @25°C
9. Working Voltage: 6-28V
10. Working Temperature: -20°C~+85°C
11. Output Interface: CAN

Package Includes:

1 x JIYI Terrain Follow Radar Sensor For K++V2
