Hobbywing Xrotor X11 Plus Power System Combo For Agricultural Drones CW

The Hobbywing XRotor X11 Plus Power System Combo (CW) is a high-efficiency, heavy-duty propulsion solution tailored for large agricultural drones. Designed to handle high payloads and long operating hours, the X11 Plus delivers up to 37 kg of thrust per rotor, ideal for spraying drones and UAVs operating in demanding environments. The clockwise (CW) rotation variant ensures proper compatibility and balance in multi-rotor drone configurations when paired with a CCW counterpart.

Its integrated design includes a powerful motor, a precisely matched FOC ESC, and a large-diameter propeller, all engineered for reliability, cooling efficiency, and maximum thrust-to-weight performance under high-voltage operation.



Features:

High Power Output

Delivers a maximum thrust of 37 kg per rotor at 54V, capable of lifting heavy spraying tanks and equipment effortlessly.

Efficient Hover Thrust Range

Optimized for 15–18 kg of typical operational thrust, ideal for sustained flight with full payload.

Weatherproof Design (IPX6)

Durable and water-resistant, perfect for outdoor and agricultural environments, including water-intensive operations.

High-Torque Brushless Motor

Equipped with an 85 KV rating and a large 111×18 mm stator for smooth power delivery and low heat generation.

CW Rotation

This version spins clockwise and should be paired with a matching CCW unit for balanced multi-rotor setups.

Premium Bearing Quality

Features Japanese-imported bearings for long service life and smooth performance.

Advanced FOC ESC Integration

The integrated ESC supports 12–14S LiPo batteries, with 150A peak current, and a fixed PWM range of 1050–1950 µs, ensuring stable, responsive control.

Large Propeller Compatibility

Optimized for 43×14" propellers, delivering high lift efficiency and quiet operation.

Wide Operating Temperature

Stable operation from 0°C to 50°C, maintaining performance in hot or moderate climates.

Package Includes:

1 X Hobbywing Xrotor X11 Plus Power System Combo For Agricultural Drones CW
